Samia Pipes, a well-respected manufacturer and supplier based in Tunis, Tunisia, specializes in high-quality Stainless Steel 316H Heat Exchanger Tubing that’s built to perform reliably in tough industrial settings. This tubing is celebrated for its exceptional high-temperature strength and resistance to corrosion, crafted using cutting-edge technology and a commitment to international standards. It’s the perfect choice for applications that demand efficient heat transfer, durability, and the ability to withstand harsh chemicals. Samia Pipes caters to a variety of industries, including petrochemicals, power generation, pharmaceuticals, food processing, and marine, providing reliable tubing solutions that promise longevity and operational efficiency.
The Stainless Steel 316H Heat Exchanger Tubing is made up of chromium (16–18%), nickel (10–14%), and molybdenum (2–3%), featuring a higher carbon content than the 316/316L grades to boost strength at elevated temperatures. It boasts a tensile strength of around 515 MPa, a yield strength of 205 MPa, and an elongation of 40%, ensuring excellent toughness and durability. The increased carbon content enhances creep resistance and mechanical stability, making it ideal for high-temperature and high-pressure applications in critical industries.
Range : 10 mm OD to 50.8 mm OD
Outer Diameter : 6.00 mm to 101.60 mm
Wall Thickness : 0.70 mm to 8.00 mm
Length : up to 20 m (65.62 ft) Length & Customed Required Length
Specifications : ASTM A 213, A 268, A 269, A 789, Equivalent to ASME, EN, JIS Etc.
| Element | SS 316H |
| C | 0.10 max |
| Mn | 2.0 max |
| Si | 0.75 max |
| P | 0.045 max |
| S | 0.030 max |
| Cr | 16.00 – 18.00 |
| Mo | 2.00 – 3.00 |
| Ni | 10.00 – 14.00 |
| Fe | 68.89 min |
| Element | SS 316H |
| Density | 8.0 g/cm3 |
| Melting Point | 1400 °C (2550 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 35 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Stainless Steel 316H Heat Exchanger Tubing from Samia Pipes and Tubes ensures superior quality and reliability. With expertise in precision manufacturing, Samia Pipes and Tubes provides 316H tubing that offers exceptional strength and corrosion resistance, especially in high-temperature and corrosive environments. Their products meet stringent industry standards, ensuring long-lasting performance in demanding applications. Additionally, Samia Pipes and Tubes is known for timely deliveries, excellent customer service, and customized solutions, making them a trusted supplier for industries like chemical processing, power generation, and oil and gas.
Samia Pipes and Tubes, one of the largest suppliers of Stainless Steel 316H Heat Exchanger Tubing in Tunis, Tunisia, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
Yes, we offer custom sizes for Stainless Steel 316H Heat Exchanger Tubing to meet your specific requirements. Our team at Samia Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@samiapipes.com.
| STANDARD | WERKSTOFF NR. | UNS | JIS |
| SS 316H | 1.4401 | S31609 | SUS 316H |
You’ll find Stainless Steel 316H Heat Exchanger Tubing widely used in heat exchangers, condensers, boilers, and pressure vessels across the chemical and petrochemical sectors, as well as in oil and gas refineries and power plants. Its outstanding corrosion resistance and ability to handle high temperatures make it a go-to for marine, pharmaceutical, and food processing applications where hygiene and durability are paramount. Moreover, it’s utilized in water treatment plants, desalination facilities, and other high-performance systems that require reliability under thermal stress. This tubing guarantees efficient heat transfer, structural integrity, and long-lasting performance even in the most challenging environments.
