Stainless Steel 317 and 317L EFW Pipes

Home > Stainless Steel >Stainless Steel 317 and 317L EFW Pipes

Stainless Steel 317 and 317L EFW Pipe Manufacturer, Supplier and Exporter in Tunis, Tunisia

Samia Pipes and Tubes, located in Tunis, Tunisia, is a trusted manufacturer and supplier of high-quality industrial pipes and tubes. Among our premium offerings are Stainless Steel 317 and 317L EFW Pipes, engineered for superior corrosion resistance, high-temperature strength, and long-term durability. Produced using the Electric Fusion Welding (EFW) process, these pipes ensure excellent dimensional accuracy and structural integrity. Ideal for chemical, petrochemical, and industrial applications, they provide reliable performance in aggressive environments. At Samia Pipes and Tubes, we deliver more than materials—we provide high-performance solutions that enhance safety, efficiency, and operational reliability.

Stainless Steel 317 EFW Pipes Supplier in Tunis, SS 317L EFW Pipes Exporter in Sfax, SS 317L EFW Pipe Manufacturer in West Tunis, 317 Stainless Steel EFW Pipe Price List in Tunisia, Stainless Steel 317L EFW Pipes Supplier in Tunis,317 High Temperature Stainless Steel EFW Pipes in Bizerte,1.4449 EFW Pipes Supplier in West Tunis

Stainless Steel 317 and 317L EFW Pipes are austenitic stainless steels containing 18% chromium, 11% nickel, and 3–4% molybdenum. The 317L variant has lower carbon content to prevent carbide precipitation, enhancing weldability and corrosion resistance. Typical tensile strength ranges from 515–720 MPa, with a yield strength of 205–450 MPa and a density of approximately 8.0 g/cm³. The EFW process ensures uniform mechanical properties, excellent dimensional accuracy, and high structural integrity, making these pipes ideal for high-temperature and chemically aggressive industrial applications.

Stainless Steel 317 and 317L EFW Pipes Specification

Specification	ASTM A358 / ASME SA358
Specification	A / SA358 CLASS 1, A / SA358 CLASS 2, A / SA358 CLASS 3, A / SA358 CLASS 4, A / SA358 CLASS 5
Grades	304, 304L, 304H, 309S, 310S, 316, 316L, 316H, 317L, 321, 321H, 347, 347H, 904L ETC.
Type	EFW, ELECTRIC FUSION WELDED
Outer Diameter Size	Electric Fusion Welded / ERW- 8″ NB To 110″ NB (Nominal Bore Size)
Wall Thickness	Schedule 10 To Schedule 160 (3 mm to 100 mm Thickness)
Length	01 Meter to 12.5 Meters, Single Random Length, Double Random Length And Customize Size.
Ends	Plain Ends / Beveled Ends
Delivery Conditions	As Rolled, Formed, Stress Relieved, Annealed, Hardened, Tempered
Coating	Electropolish, Mechanical Polish, Satin Finish, Passivated
Dimension	All Pipes Is Manufactured and Inspected / Tested to the Relevant standards including ASTM and ASME
Value Added Services	Draw / Expansion / Machining / Sand Blasting / Shot Blasting / Heat Treatment
Packaging	Loose / Bundle / Wooden Pallet / Wooden Box / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector
Material Test Certificate	Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS ETC

Equivalent Grades for Stainless Steel 317 and 317L EFW Pipes

STANDARD	UNS	WERKSTOFF NR.	EN	JIS
SS 317	S31700	1.4449	–	SUS 317
SS 317L	S31703	1.4438	X2CrNiMo18-15-4	SUS 31

317 and 317L Stainless Steel EFW Pipes Chemical Composition

Grade	C	Mn	Si	P	S	Cr	Mo	Ni	Fe
SS 317	0.08 max	2.0 max	1.0 max	0.045 max	0.030 max	18.00 – 20.00	3.00 – 4.00	11.00 – 15.00	57.845 min
SS 317L	0.035 max	2.0 max	1.0 max	0.045 max	0.030 max	18.00 – 20.00	3.00 – 4.00	11.00 – 15.00	57.89 min

SS 317 and 317L EFW Pipes Mechanical Properties

Tensile Strength	Yield Strength (0.2%Offset)	Elongation	Hardness
			Rockwell B (HR B) max	Brinell (HB) max
Psi – 75000, MPa – 515	Psi – 30000, MPa – 205	35 %	95	217

If You Are Looking To Buy High Quality

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

TP 317L SS EFW Pipe Supplier in Tunisia, 317 Austenitic Stainless Steel EFW Pipes Exporter in West Tunis, EFW Pipe Stainless Steel UNS S31703 Manufacturer in Tunis,Stainless Steel 317 EFW Pipes Supplier in Tunis, SS 317L schedule 10 EFW Pipe Exporter in Sousse

Why Choose Stainless Steel 317 and 317L EFW pipes from Samia Pipes and Tubes?

Choosing Stainless Steel 317 and 317L EFW Pipes from Samia Pipes and Tubes guarantees excellent corrosion resistance, high strength, and durability. Designed for diverse industrial applications, it delivers reliable performance in tough environments while maintaining competitive pricing for cost-effective solutions.

Customer Support

On Time Deliveries

Largest Inventory

Worldwide Shipping

Largest Stainless Steel 317 and 317L EFW pipes Supplier in Tunis, Tunisia

Samia Pipes and Tubes, a leading manufacturer and supplier of Stainless Steel 317 and 317L EFW Pipes in Tunis, Tunisia, offers a comprehensive range of high-quality pipes and tubing suitable for various industrial applications. Our extensive inventory and commitment to exceptional service make us a trusted choice for regional products.

EFW SS 317 Pipes Exporter in Tunisia, SS UNS S31700 EFW Pipe Price List in Tunis, SS 317 EFW Pipe Supplier in Sfax, 317 SS EFW Pipes Exporter in West Tunis, Stainless Steel 1.4438 EFW Pipes Exporter in Tunis,SUS 317L EFW Pipes Price in Bizerte, 317 Stainless Steel EFW Pipes Weight Chart, Stainless Steel 317 EFW Pipes Thickness, SS S31700 EFW Pipes Supplier in Tunisia

317 and 317L Stainless Steel EFW Pipe Sizes

NPS Designator	Outside Diameter		Nominal Wall Thickness
	in.	mm	Schedule 5SA		Schedule 10SA		Schedule 40SA		Schedule 80SA
	in.	mm	in.	mm	in.	mm	in.	mm	in.	mm
8	8.625	219.08	0.109	2.77	0.148	3.76	0.322	8.18	0.500	12.70
10	10.750	273.05	0.134	3.40	0.165	4.19	0.365	9.27	0.500B	12.70B
12	12.750	323.85	0.156	3.96	0.180	4.57	0.375B	9.52B	0.500B	12.70B
14	14.000	355.60	0.156	3.96	0.188B	4.78B	…	…	…	…
16	16.000	406.40	0.165	4.19	0.188B	4.78B	…	…	…	…
18	18.000	457.20	0.165	4.19	0.188B	4.78B	…	…	…	…
20	20.000	508.00	0.188	4.78	0.188B	4.78B	…	…	…	…
22	22.000	558.80	0.188	4.78	0.218B	5.54B	…	…	…	…
24	24.000	609.60	0.218	5.54	0.250	6.35	…	…	…	…
30	30.000	762.00	0.250	6.35	0.312	7.92	…	…	…	…

Physical Properties of SS 317 and 317L EFW Pipes

Physical Properties (Room Temperature)
Specific Heat (0-100°C)	500	J.kg-1.°K-1
Thermal Conductivity	14.6	W.m -1.°K-1
Thermal Expansion	16.5	mm/m/°C
Modulus Elasticity	193	GPa
Electrical Resistivity	7.4	μohm/cm
Density	7.99	g/cm

Types of Stainless Steel 317 and 317L EFW Pipes

Are Custom Sizes Available for Stainless Steel 317 and 317L EFW Pipes?

We offer custom sizes for Stainless Steel 317 and 317L EFW Pipes to meet your specific needs. Our dedicated team at Samia Pipes and Tubes provides tailored solutions for all your piping and tubing requirements. For more information, contact us at sales@samiapipes.com.

SUS 317L EFW Pipes Tunis,317 Stainless Steel EFW Pipe Supplier in Sfax, ASTM A358 TP317 EFW Stainless Pipe Manufacturer in West Tunis, TP 317L SS EFW Pipe Exporter in Bizerte, Stainless Steel 1.4438 EFW Pipes Dealer in Tunis, SS 317L EFW Pipe Supplier in Tunisia

Stainless Steel 317 and 317L EFW Pipes are widely used in industries where corrosion resistance, durability, and high-temperature performance are critical. They are ideal for chemical processing plants, petrochemical industries, offshore and marine applications, and saltwater systems. In pharmaceutical, food processing, and desalination industries, they provide safe, contamination-free transport of aggressive fluids. Additionally, they are used in high-temperature piping systems, heat exchangers, and boiler components. With their combination of mechanical strength, chemical resistance, and weldability, Stainless Steel 317 and 317L EFW Pipes from Samia Pipes and Tubes deliver efficient, low-maintenance, and high-performance solutions for demanding industrial applications.
